OMCN

Electromechanical 2-post lift

Technical and Structural Layout

• Electromechanical operating.
• Lifting through trapezoidal turning screws, made of high resistance steel with fine pitch so that trolleys may become self-braking.
• Completely protected internal sliding trolleys.
• Load-bearing nuts from a special material, to minimise lubrification.
• Self-protected safety nuts.
• Monocoque body column structure.
• Four sliding rollers for each trolley, plus four adjustable guide-shoes guarantee a perfect adhesion and flowability.
• Movement transmission between screws through a chain with electric antislowing protection, in order to guarantee an operating silentness and a higher elasticity.
• Over-sized electric motor with thermic overload protection.
• Closed-course electrical system, with low-voltage drives and endstrokes,“man standing-by” operating.
• Epoxy powder painting.
• Completely pre-assembled frame.
• Equipped with greasing pump.
• Equipped with anchor small blocks.

Electrohydraulic 2-Post Lift

Technical and Structural Layout

• Electrohydraulic functioning.
• Maintenance interventions reduced to the minimum thanks to the long life of the lift’s components and the total absence of cables, chains, pulleys, bearings, screws and lead nuts.
• Alignment and synchronism of the two saddles independently of the load distribution.
• Mechanical safety supports with automatic connection.
• Safety valves mounted directly into the cylinders.
• Safety device in presence of obstructions during the descent phase.
• Speed compensated control.
• Overload valve.
• Feet protection and automatic arm locking device.
• Low voltage 24 V “man standing-by” controls.
• Vehicle anti-collision device on the upper crosspiece.
• Epoxy powder painting.
• Equipped with anchor small blocks.
• Delivered with oil for the hydraulic circuit.

Electrohydraulic 4 Post Lift

Technical and Structural Layout

• 4-post auto lifts, electrohydraulic functioning.
• With specifically designed structures, the internal working space and the dimensions of the platforms make it possible to lift from small to large vehicles.
• Safety devices lock the auto lift in case of slack and/or cable failure.
• Aluminium pulley with ball bearing.
• 3-phases safety level: mechanical anchors on the rack, cable anti-breaking system and additional electric safety.
• Safety valves both stop over capacity lifting and hydraulic failure.
• 24 V safety system.
• Equipped with anchor small block.

Electromechanical 4-post lift

Technical and Structural Layout

• Electromechanic functioning.
• Lifting through trapezoidal turning screws, made of high resistance steel with fine pitch so that trolleys may become self-braking.
• Bronze bearing female nut together with a second safety female nut of the same height and of the same top material quality, self-protected by electrical safety.
• Completely protected internal sliding trolleys.
• Slides in full drawn solid steel at high resistance.
• 6 wheels with big diameter and in high-resistance steel for each trolley guarantee a perfect adhesion an flowability.
• Lubrification of the screw assured by a device mounted directly on the bearing nut.
• Synchronization between the four trolleys regulated by an operational PLC which controls the realignment in presence of a difference of more than 15 mm.
• Footboards of big dimensions, of which one transversally adjustable.
• Electric engines of top-building factory delivering more power.
• 24 V general transformer, top-choice electric components, self-protected general plant in order to guarantee the total efficiency of all the safety measures, “man standing-by” command.
• Epoxy powder painting of all mostly exposed parts.
• Equipped with anchor small blocks

Contact us for all of your OMCN requirements.
